CFM202S Series

CFM202S Series, 200 Watt Chassis Mounting Single Output Power Supplies



CFM202SXXXB = Open Frame with Baseplate

CFM202SXXXC = Enclosed Metal Case

Features

  • High Efficiency up to 94%
  • 2”x 4” Open Frame Compact Size
  • 150W with Natural Convection (CFM202SXXXB) - Open Frame with Baseplate
  • 180W with Natural Convection (CFM202SXXXC) - Enclosed Metal Case
  • 200W with Fan-Cooling
  • No Load Input Power Consumption<150mW
  • Approved Safety IEC/EN/UL 62368-1
  • Meets IEC/EN60335-1
  • Operating Altitude 5000m
  • Continuous Short Circuit Protection
  • Over Voltage Protection
  • Over Temperature Protection
  • Active PFC Function

Models and Ratings

ModelInput VACOutput VDCOutput CurrentSize
CFM202S12090~26412 Volts16.66 Amps101.6 x 50.8 x 33mm
CFM202S24090~26424 Volts8.33 Amps101.6 x 50.8 x 33mm
CFM202S28090~26428 Volts7.14 Amps101.6 x 50.8 x 33mm
CFM202S36090~26436 Volts5.56 Amps101.6 x 50.8 x 33mm
CFM202S48090~26448 Volts4.17 Amps101.6 x 50.8 x 33mm
CFM202S56090~26456 Volts3.58 Amps101.6 x 50.8 x 33mm
