EC3AW-3 Watt

EC3AW Series, 3 Watt Through Hole DC-DC Converter

24 Pin DIL/SMD Package

500/1500/3000 VDC Isolation options

4:1 Inputs

Regulated Single and Dual Output

Model	Input VDC	Output VDC	Output Current	Size (24 Pin DIL)
EC3AW07	9~36 Volts	3.3 Volts	600mA	31.8 x 20.3 x 10.2mm
EC3AW01	9~36 Volts	5 Volts	600mA	31.8 x 20.3 x 10.2mm
EC3AW02	9~36 Volts	12 Volts	250mA	31.8 x 20.3 x 10.2mm
EC3AW03	9~36 Volts	15 Volts	200mA	31.8 x 20.3 x 10.2mm

EC3AW17	18~72 Volts	3.3 Volts	600mA	31.8 x 20.3 x 10.2mm
EC3AW11	18~72 Volts	5 Volts	600mA	31.8 x 20.3 x 10.2mm
EC3AW12	18~72 Volts	12 Volts	250mA	31.8 x 20.3 x 10.2mm
EC3AW13	18~72 Volts	15 Volts	200mA	31.8 x 20.3 x 10.2mm

Model	Input VDC	Output 1	Output 2	Size (24 Pin DIL)
EC3AW04	9~36 Volts	+5 Volts / +300mA	-5 Volts / -300mA	31.8 x 20.3 x 10.2mm
EC3AW05	9~36 Volts	+12 Volts / +125mA	-12 Volts / -125mA	31.8 x 20.3 x 10.2mm
EC3AW06	9~36 Volts	+15 Volts / +100mA	-15 Volts / -100mA	31.8 x 20.3 x 10.2mm

EC3AW14	18~72 Volts	+5 Volts / +300mA	-5 Volts / -300mA	31.8 x 20.3 x 10.2mm
EC3AW15	18~72 Volts	+12 Volts / +125mA	-12 Volts / -125mA	31.8 x 20.3 x 10.2mm
EC3AW16	18~72 Volts	+15 Volts / +100mA	-15 Volts / -100mA	31.8 x 20.3 x 10.2mm

* Use Suffix 'M' for Metal Case Verson

* Use Suffix 'H' for 3000VDC Isolation (Plastic case only )

* Use Suffix 'HM' for 1500VDC Isolation and metal case

* Use Suffix 'MS' for metal case & Surface mount package

* Use Suffix 'HMS' for 1500 VDC Isolation, metal case & surface mount package
