YNC40-40 Watt

YNC40 Series, 40 Watt DC-DC Converter

2″x 1″ Package

1600 VDC Isolation

8:1 Inputs

Regulated Single and Dual Output



  • 40W Isolated Output
  • 2’’x 1’’ Six-Sided Shield Metal Case
  • Efficiency to 92%
  • 8:1 Input Range
  • Regulated Outputs
  • No Minimum Load Required
  • Operating Temperature: -40℃ To +60℃
  • Over Power and Short Circuit Protection
  • Over Temperature Protection
  • 3 Years Warranty

Models and Ratings

ModelInput VDCOutput VDCOutput CurrentSize (2"x 1")
YNC40-36S059~75 Volts5 Volts8000mA50.8 x 25.4 x 11.6mm
YNC40-36S129~75 Volts12 Volts3333mA50.8 x 25.4 x 11.6mm
YNC40-36S159~75 Volts15 Volts2667mA50.8 x 25.4 x 11.6mm
YNC40-36S249~75 Volts24 Volts1667mA50.8 x 25.4 x 11.6mm

Dual Output Models

ModelInput VDCOutput 1Output 2Size (2"x 1")
YNC40-36D129~75 Volts+12 Volts / +1667mA-12 Volts / -1667mA50.8 x 25.4 x 11.6mm
YNC40-36D159~75 Volts+15 Volts / +1333mA-15 Volts / -1333mA50.8 x 25.4 x 11.6mm
